ASME B36.19 - ASTM A-312
ASME B36.19 - ASTM A-312
|
D. INCH |
D.E mm |
SCH 10S |
SCH 40S |
SCH 80S |
|||
|
SP/THICK |
KG/MTR |
SP/THICK |
KG/MTR |
SP/THICK |
KG/MTR |
||
|
1/2" |
21.34 |
2.11 |
1.00 |
2.77 |
1.26 |
3.73 |
1.62 |
|
3/4" |
26.67 |
2.11 |
1.28 |
2.87 |
1.68 |
3.91 |
2.19 |
|
1" |
33.40 |
2.77 |
2.08 |
3.38 |
2.50 |
4.55 |
3.23 |
|
1 1/4" |
42.16 |
2.77 |
2.69 |
3.56 |
3.38 |
4.85 |
4.46 |
|
1 1/2" |
48.26 |
2.77 |
3.11 |
3.68 |
4.05 |
5.08 |
5.40 |
|
2" |
60.30 |
2.77 |
3.93 |
3.91 |
5.43 |
5.54 |
7.47 |
|
2 1/2" |
73.03 |
3.05 |
5.25 |
5.16 |
8.62 |
7.01 |
11.40 |
|
3" |
88.90 |
3.05 |
6.44 |
5.49 |
11.28 |
7.62 |
15.25 |
|
3 1/2" |
101.60 |
3.05 |
7.39 |
5.74 |
13.56 |
8.08 |
18.62 |
|
4" |
114.30 |
3.05 |
8.35 |
6.02 |
10.06 |
8.56 |
22.29 |
|
5" |
141.30 |
3.40 |
11.56 |
6.55 |
21.76 |
9.52 |
30.92 |
|
6" |
168.30 |
3.40 |
13.82 |
7.11 |
23.23 |
10.97 |
42.52 |
|
8" |
219.10 |
3.76 |
19.94 |
8.18 |
42.49 |
12.70 |
64.57 |
