EN 1092-1 TYPE 01/A PN 10
Cheap version of casting flanges available on request
EN 1092-1 TYPE 01/A PN 10
Cheap version of casting flanges available on request
|
DN |
D |
d1 |
b |
Fori | Holes |
Peso Kg Weight Kg |
||
|
a |
f |
N° fori holes |
|||||
|
Da DN15 a DN50 dimensioni identiche con PN40 / From DN15 to DN50 dimensions identical with PN40 |
|||||||
|
Da DN65 a DN150 dimensioni identiche con PN16 / From DN65 to DN150 dimensions identical with PN16 |
|||||||
|
200 |
340 |
221,5 |
24 |
295 |
22 |
8 |
10,30 |
|
250 |
395 |
276,5 |
26 |
350 |
22 |
12 |
14,00 |
|
300 |
445 |
327,5 |
26 |
400 |
22 |
12 |
15,50 |
|
350 |
505 |
359,5 |
30 |
460 |
22 |
16 |
23,00 |
|
400 |
565 |
411,0 |
32 |
515 |
26 |
16 |
29,00 |
|
450 |
615 |
462,0 |
36 |
565 |
26 |
20 |
35,00 |
|
500 |
670 |
513,5 |
38 |
620 |
26 |
20 |
42,00 |
|
600 |
780 |
616,5 |
42 |
725 |
30 |
20 |
54,00 |
|
700 |
895 |
- |
- |
840 |
30 |
24 |
66,00 |
|
800 |
1.015 |
- |
- |
950 |
33 |
24 |
90,00 |
|
900 |
1.115 |
- |
- |
1.050 |
33 |
28 |
103,00 |
|
1.000 |
1.230 |
- |
- |
1.160 |
36 |
28 |
131,00 |
EN 1092-1 TYPE 01/A PN 6
EN 1092-1 TYPE 01/A PN 16
EN 1092-1 TYPE 01/A PN 40
