FEMALE-MALE REDUCERS

ANSI B16.11
3000 LBS

rid-fm

FEMALE-MALE REDUCERS

ANSI B16.11
3000 LBS

Diam. nominale

Nominal pipe size

3000

M (1)

N (1)

mm

inches

mm

inches

3/8" x 1/4"

42

1.50

22

0.87

1/2" x 3/8"

49

1.81

28

1.10

1/2" x 1/4"

49

1.81

28

1.10

3/4" x 1/2"

59

2.01

35

1.38

1" x 3/4"

63

2.36

45

1.77

1" x 1/2"

61

2.36

45

1.77

1" x 1/4"

60

2.36

45

12.77

1 1/4" x 1"

68

2.68

60

2.24

1 1/2" x 1"

72

2.76

65

2.56

1 1/2" x 3/4"

67

2.76

65

2.56

1 1/2" x 1/2"

67

2.76

65

2.56

2" x 1/2"

70

2.95

76

2.99

2" x 1"

75

2.95

76

2.99

2 1/2" x 2"

92

3.74

95

3.74

3" x 2"

95

3.94

110

4.33

4" x 3"

113

4.33

140

5.51

4" x 2"

100

4.33

140

5.51
Thread according to ANSI B1.20.1
(1) Dimensions not listed in ANSI B 16.11-1980 and BS 3799-1974 may vary according to the manufacturer.
