ANSI B16.11
3000 - 6000 LBS
ANSI B16.11
3000 - 6000 LBS
|
Diam. nominale Nominal pipe size |
3000 |
6000 |
||||||
|
Q (1) |
R (1) |
Q (1) |
R (1) |
|||||
|
mm |
inches |
mm |
inches |
mm |
inches |
mm |
inches |
|
|
1/4" |
42.5 |
1.67 |
36.0 |
1.42 |
54.0 |
2.13 |
46.0 |
1.81 |
|
3/8" |
47.5 |
1.87 |
41.0 |
1.62 |
57.0 |
2.25 |
51.0 |
2.00 |
|
1/2" |
52.0 |
2.05 |
46.0 |
1.81 |
69.0 |
2.72 |
60.0 |
2.36 |
|
3/4" |
57.0 |
2.25 |
56.0 |
2.20 |
72.0 |
2.84 |
72.0 |
2.84 |
|
1" |
63.0 |
2.48 |
65.0 |
2.56 |
80.0 |
3.15 |
80.0 |
3.15 |
|
1 1/4" |
68.0 |
2.76 |
80.0 |
3.07 |
89.0 |
3.50 |
94.0 |
3.70 |
|
1 1/2" |
78.0 |
3.07 |
88.0 |
3.39 |
108.0 |
4.25 |
100.0 |
3.94 |
|
2" |
91.0 |
3.50 |
105.0 |
4.06 |
114.0 |
4.49 |
122.0 |
4.80 |
|
2 1/2" |
120.0 |
4.49 |
122.0 |
4.80 |
130.0 |
5.13 |
144.0 |
5.67 |
|
3" |
140.0 |
5.12 |
144.0 |
5.67 |
150.0 |
5.91 |
180.0 |
7.09 |
|
4" |
148.0 |
5.91 |
200.0 |
7.09 |
||||
